β-Ga₂O₃ substrates and epi-wafers


  • BRAND: Novel Crystal Technology Inc.,
  • DESCRIPTION:
    2 inch β-Ga₂O₃ epitaxial wafer (by HVPE)
    100 mm β-Ga₂O₃ epitaxial wafer (by HVPE)
    10×15mm² β-Ga₂O₃ epitaxial wafer (by MBE)
  • Nation of Principal:USA
    Product Application:Semiconductor Front end manufacturing (wafer fabrication) materials
    Keyword:β-Ga₂O₃

    These products must be used for research and development purposes only.
    The epi-wafers and substrates must not be used as a seed crystal.

1.The only manufacturer of large-diameter, high quality β-Ga₂O₃ single-crystal substrates in the world.
2. The only manufacturer of low defect density and high purity β-Ga₂O₃ epitaxial layers
