APET-Koera http://www.apet.co.kr Advanced semiconductor wet process machine manufacturer 1. Marangoni Dryer unit 2. Wet bench & Single wafer design 3. Wet tool manufacturing
Clean Control Tech http://www.cctkr.com CCT Clean Control Tech has been proding various Cleanroom and ESD products to prevent Dust, Static charge, Especially, CCT has been well know for excellent quality of Sticky Mat, Roller, ESD tap, and now is leading company in world clean room market.
COSMOTEC http://www.cosmotec.us Ceramic-to-Metal & electrical feedthroughs for ultra-high vacuum (UHV) applications.
Freiberg Instrument http://www.freiberginstruments.de/ Inline & offline lifetime mapping for both wafer & ingot for solar cell.
GOOD TECH INSTRUMENTS http://www.goodtechnology.com.tw/ At the beginning of the establishment of GOOD TECH is committed to the measurement and control technology research and development, and practical application of various types of sensing elements and sensors to build their own measurement technology, expect to propose the fastest and most accurate program for customers Resolve any problems encountered on the production line or machine equipment. people oriented The team has integrated years of experience in user and instrument development and developed a simple user interface with the APP operating practices of the current mobile device, and integrated the diverse and complete standard database, non-professional users Can be easy to use, the real implementation of the value of technology applications.
Hitachi FOPLP Plating http://www.hitachi-power-solutions.com/en/products/equipment/plating_apparatus/index.html 1.Ni-Solder continuous plating 2.Suitable for (Cu/Ni/SnAg, Cu/Ni/Au) fan-out package substrate plating 3.Handles ne pitch pattern plating 4.Duplex simultaneous treatment and high throughput with compact
Japan JEL Corporation http://www.jel-robot.com/ Manufacturing the robot of high level, applied to the semiconductor wafer and FPD substrate transfer operations

Founded in 1993, JEL is famous in the semiconductor and panel industry for her high technology design and precision moving. In the past 20 more years, JEL have served the worldwide customers by using their huge data base which is full of their experiences and test data from the first beginning. The customized product is also the important part of robot business. Realizing the detail of customers’ needs, from EE to robot body, JEL can provide a whole set design by discussing with customers. Even provide the newest element for better performance, both in JEL robot & user’s system. Being the agent of JEL, CIC welcomes you to join the new age of robot and create the more competitive systems together.
KURABO https://www.kurabo.co.jp/el/world/en/products/chemical_liquid/index.html KURABO’s Concentration Meter features long-term stability, high accuracy, and high response speed. Simple design Simple operation method with simplified operation buttons. Easier maintenance with less wear Only regular replacement of a lamp inside the unit is required. Achieves reduction of downtime with superior durability. Measurement principle not affected by the environment Enables measurement without being affected by a small amount of turbidity, bubbles, or temperature fluctuation.
Noah Precision, LLC http://www.noahprecision.com Thermoelectric temperature control system for Plasma processing, Static chiller: Provide temperature control for vacuum chamber and chuck
Laytec http://www.laytec.de Real-time measurement of III-V Compounds , III-Nitrides II-VI Compounds , IV-IV Compounds
Lumineq http://lumineq.com/ Lumineq® Displays, a business unit of Beneq, is the world’s premier manufacturer and developer of thin film electroluminescent (TFEL) displays. Lumineq TFEL non-transparent displays are used in mining, marine, military, medical and many more demanding environments. TFEL displays are robust and reliable, and usually used in extreme environments, where traditional displays cannot cope with the conditions.
Lumineq transparent TASEL® displays combine the rugged and reliable build of TFELs with the unique freedom of designing a completely transparent display. TASEL is ideal for consumer electronics, architectural use and other fields where viewing experience and product aesthetics is of paramount importance.
America MaxMile http://www.maxmiletech.com/ EL(Electro Luminescent) property measurement system/ EpiEL Mapping System
MHI http://www.mhi.co.jp/en/index.html Wafer bonder machine supplier. Application: MEMS, LED, TSV, and 3D IC package.
MHI ABLASER http://www.mhi-global.com/news/story/1610272028.html Scanning acoustic microscopy offers you a wide application portfolio in materials and failure analysis in the fields of industrial manufacturing, semiconductor and in nearly all applications of applied research.
America MMI https://www.micromaterials-inc.com/index.html Micro Materials Inc. (MMI) is a cutting-edge technology company dedicating to developing innovative wafer handling and processing yield improvement solutions for fan-out wafer level packaging, 3D vertical IC integration, and advanced packaging for MEMS, LED and CMOS image sensors. Our patented AirDebond® technology allows for fast and low stress debonding down to less than 15 µm.
Jiangsu Nata Optoelectronic Material.Co.,Ltd. http://www.natachem.com supplier of high purity metal organic compound,ex.TMGa TMIn DEZn Cp2Mg…
America n&k http://www.nandk.com/ n&k Technology manufactures state-of-the-art scatterometry (OCD) and thin film metrology tools for the semiconductor, photomask, data storage, flat panel display and solar cell industries. n&k Technology’s ultra-high resolution metrology systems have low cost of ownership and are used for film thickness, n and k, depth, CD and profile measurements of the most challenging thin film and OCD structures.
Noda Techno Ultra-thin capacitor http://www.nodatechno.com/index.html For Low-power and High-speed LSI operation, improvement of power integrity is essential. Our Ultra-thin STO Capacitor, which can be placed inside WLP (under RDL) or on package PWB, enables very low power impedance at high frequency range nearby LSI, and realizes high quality power environment.
PFK instrument http://www.pfkco.com PFK提供用於研究和工業應用的設備零件。 PFK的目標是成為我們客戶的價值供應商。 提供半導體用晶片式溫度計:PFK provides equipment parts for research and industrial applications. PFK's goal is being the VALUE Supplier to our customers. Provides TC wafers as below: 1. With different type(K, R, S type) 2. Homemade software can correspond to KLA TC wafer 3.With wireless measurement function 4.Customized,Maximum measurement points up to 48 points. 1. 具有K,R,S type 2. 自製軟體可對應KLA TC wafer 3.具有無線量測功能 4.可客製化,最高量測點數高達48點
Japan PNP http://www.pnp.co.jp/products_3_1e.html Tera Evaluator using new Thz ellisometer to measurement nontransparent think film thinkness. Non-Contact Epi-Si/Sic Surface Measurement for Carrier Density / Mobility / Dopant thickness
Germany PVA TePla CSAM https://www.pvatepla-sam.com/en/ Scanning acoustic microscopy offers you a wide application portfolio in materials and failure analysis in the fields of industrial manufacturing, semiconductor and in nearly all applications of applied research.
USA Quad http://www.quadgroupinc.com/index.html Ultra-precise measurement of your film adhesion
SAINT-GOBAIN https://www.processsystems.saint-gobain.com/products/electronics High Purity Pumps High purity pumps are 100% metal-free and elastomer-free, protecting contents against contamination during the handling of aggressive or high purity chemicals within semiconductor applications. Designed for preventative maintenance and easy disassembly/reassembly, our larger pumps are used for transporting and pumping bulk chemicals. Smaller versions are ideal for etching applications and for handling chemical mechanical polishing liquids that contain High Purity Valves High purity valves are integral to liquid handling in semiconductor processing, where aggressive chemicals, ultra-high-purity chemicals, and chemical mechanical polishing liquids are transferred. Our valves offer improved flow capabilities and stronger performance against back pressure, resulting in higher process efficiency and reduced operations down-time.
SENTECH Instruments GmbH http://www.sentech.com 1.Thin film measurement tools, including reflectometer, laser ellipsometer, spectroscopic ellipsometers, and automatic model for routine quality control. 2.Plasma processing tools, including ICP, RIE, PECVD & ICPECVD systems.
USA Sigray http://www.sigray.com Micro x-ray fluorescence is a powerful spatially-resolved elemental mapping and chemical microanalysis technique. Under x-ray illumination, a sample will produce characteristic x-rays that can be analyzed to determine composition. MicroXRF advantages include: Higher sensitivity (in comparison to electron-based techniques such as microprobes) Non-destructive for in situ or in operando analysis of elemental migration Simultaneous detection of multiple elements and no sample preparation required
SVXR https://www.svxr.com/ Advanced Process Control Delivered to OSATs & Foundries with packaging: 1.Automation: Fully automated load/unload for Package 2.Reconstituted Substrates: strip/panel, or wafers 3.High Sensitivity: Defects in Solder quality, wetting, voids and alignment of die
Japan TAKANO https://www.takano-net.co.jp/portal/en/field/image_inspection/ Beginning in 1987, when Takano Image Processing and Measurement Division first released its original brand of image processing inspection equipment, we have striven to continually improve the functionality of our products and expanded the range of applications. Takano now offers an extensive lineup of state-of-the-art products starting IC package inspection system, FPD(flat panel display) inspection system, film inspection system, battery-related material inspection system and measuring systems such as AFM (Automatic Force Microscope) and others.
TECHNOMATE High Pressure pump https://www.technomate.co.jp/en/ Designed by the Japanese company Technomate, the company focuses on the design and manufacturing of semiconductor peripherals under the theme of "temperature, pressure and fluid science". Available for explosion-proof areas because electricity is not used with air driven plunger pumps Ideal for incorporating lift-off devices, etc.
Teledyne http://teledyne.com/ 1.Ozone Analyzers 2.Ozone Generators 3.Ozone Destruct Systems 4.Ozone Delivery Systems
Germany WAVELABS http://www.wavelabs.de/ Solar Metrology Systems
